Model
number
| Screw
diameter
d
| lead
I
| Ball
diameter
Da
| Root
diameter
dr
| Turn
x
Circuit
| Load
rating
Ca /Coa
Kgf /Kgf
| Stiffen
Kg/um
|
| SRF-1605A
| 16
| 5
| 3.175(1/8")
| 13.4
| 2.5x1(1-tube)
| 750
/ 1400
| 16
|
| SRF-1605B
| 5
| 3.175(1/8")
| 13.4
| 2.5x2(2-tube)
| 1360
/ 2800
| 33
|
| SRF-2005B
| 20
| 5
| 3.175(1/8")
| 17.4
| 2.5x2(2-tube)
| 1530
/ 3520
| 38
|
| SRF-2505B
| 25
| 5
| 3.175(1/8")
| 22.4
| 2.5x2(2-tube)
| 1690
/4470
| 46
|
| SRF-2805B
| 28
| 5
| 3.175(1/8")
| 25.4
| 2.5x2(2-tube)
| 1780
/ 4990
| 50
|
| SRF-2806B
| 6
| 3.969((5/32")
| 24.7
| 2.5x2(2-tube)
| 2380
/ 6100
| 52
|
| SRF-3205B
| 32
| 5
| 3.175(1/8")
| 29.4
| 2.5x2(2-tube)
| 1870
/ 5740
| 55
|
| SRF-3206B
| 6
| 3.969(5/32")
| 28.7
| 2.5x2(2-tube)
| 2520
/ 7120
| 57
|
| SRF-3606B
| 36
| 6
| 3.969(5/32")
| 32.7
| 2.5x2(2-tube)
| 2730
/ 8100
| 64
|
| SRF-3610B
| 10
| 6.350(1/4")
| 31.1
| 2.5x2(2-tube)
| 5010
/ 12450
| 67
|
| SRF-4010B
| 40
| 10
| 6.350(1/4")
| 35.1
| 2.5x2(2-tube)
| 5320
/ 14080
| 73
|
| SRF-4510B
| 45
| 10
| 6.350(1/4")
| 40.1
| 2.5x2(2-tube)
| 5630
/ 16070
| 81
|
| SRF-5010B
| 50
| 10
| 6.350(1/4")
| 45.1
| 2.5x2(2-tube)
| 5910
/ 17860
| 88
|
Model
number
| Nut(Dimension)
| Screw
shaft length
|
Body
D
| Flange
A
| H
| Ln
| T
| PCD
| Set
hole
| Q
| Ls
| L1(Ls-L2)
| L2
| C
| B
|
| X
/ Y / Z
|
| SRF-1605A
| 40
| 60
| 23
| 41
| 10
| 50
| 4.5/8/4.5
| M6
| 610.810.1010
| 550.700.900
| 80
| 5
| 30
|
| SRF-1605B
| 40
| 60
| 23
| 56
| 10
| 50
| 4.5/8/4.5
| M6
| 610.810.1010
| 550.700.900
| 80
| 5
| 30
|
| SRF-2005B
| 44
| 67
| 26
| 55
| 11
| 55
| 5.5/9/5.5
| M6
| 610.810.1010
| 550.700.900
| 110
| 5
| 40
|
| SRF-2505B
| 50
| 73
| 28
| 55
| 11
| 61
| 5.5/9/5.5
| M6
|
610.810.1010
1210.1410.
| 480.680.880
1080.1280
| 130
| 5
| 50
|
| SRF-2805B
| 55
| 84
| 31
| 56
| 12
| 69
| 6.5/10.5/6.5
| M6
| 610.810.1010
1210.1410
| 480.680.880
1080.1280
| 130
| 5
| 50
|
| SRF-2806B
| 55
| 84
| 31
| 63
| 12
| 69
| 6.5/10.5/6.5
| M6
| 610.810.1010
1210.1410
| 480.680.880
1080.1280
| 130
| 5
| 50
|
| SRF-3205B
| 58
| 84
| 32
| 56
| 12
| 71
| 6.5/10.5/6.5
| M6
| 610.810.1010
1210.1510
| 450.650.850
1050.1350
| 160
| 5
| 60
|
| SRF-3206B
| 62
| 89
| 34
| 63
| 12
| 75
| 6.5/10.5/6.5
| M6
| 610.810.1010
1210.1510
| 450.650.850
1050.1350
| 160
| 5
| 60
|
| SRF-3606B
| 65
| 99
| 38
| 67
| 15
| 82
| 9/14/8.5
| M6
| 810.1010.1210
1510.1810
| 630.830.1030
1330.1630
| 180
| 5
| 70
|
| SRF-3610B
| 75
| 119
| 45
| 100
| 18
| 98
| 11/17.5/11
| M6
| 810.1010.1210
1510.1810
| 630.830.1030
1330.1630
| 180
| 10
| 70
|
| SRF-4010B
| 82
| 124
| 47
| 100
| 18
| 102
| 11/17.5/11
| 1/8"
| 1210.1510.1810
2110.2410
| 1030.1330.1630
1930.2230
| 180
| 10
| 80
|
| SRF-4510B
| 88
| 132
| 47
| 100
| 18
| 102
| 11/17.5/11
| 1/8"
| 1210.1510.1810
2110.2410
| 1030.1330.1630
1930.2230
| 180
| 10
| 80
|
| SRF-5010B
| 93
| 135
| 51
| 100
| 18
| 113
| 11/17.5/11
| 1/8"
| 1210.1510.1810
2110.2410
| 1010.1310.1610
1910.2210
| 200
| 10
| 90
|
|
|
|
|
|
|
