 ¢º KURODA BALL SCREW GY SERIES (U-NUT)





Model number


outside
diameter
d


lead
L

Screw Shaft

Nut size

Basic
load rating

Flange size

Thread
length
§¤1

Overall
length
§¤t

Shaft
end length
§¤2

Outside
diameter
D

Overall
length
 Lt

Body
length
F

Outside
diameter
D1


T

Width
W

P.C.D.
P

C
(daN)

Co
(daN)

GY1210AS-HULR-

0400

0800 A

12

10

340

400

60

30

44

32

54

12

32

41

285

495

740

800

GY1505DS-HULR-

0600

1200 A

15

5

540

600

60

34

40

30

54

10

34

44

510

1050

1140

1200

GY1510DS-HULR-

0600

1200 A

10

540

600

52

42

57

10

34

45

510

1050

1140

1200

GY1516BS-HULR-

0600

1200 A

16

540

600

32

51

41

53

10

32

42

430

1020

1140

1200

GY1520BS-HULR-

0600

1200 A

20

540

600

34

59

49

57

10

34

45

580

1330

1140

1200

GY2005DS-HULR-

0600

1200 A

2000

20

5

520

600

80

40

40

30

60

10

40

50

620

1470

1120

1200

1920

2000

GY2010DS-HULR-

0600

1200 A

2000

10

520

600

52

57

45

82

12

52

67

1060

2270

1120

1200

1920

2000

GY2020DS-HULR-

0600

1200 A

2000

20

520

600

39

78

68

62

10

39

50

620

1470

1120

1200

1920

2000

GY2505DS-HULR-

1000

2000 A

2500

25

5

890

1000

110

43

40

30

67

10

43

55

660

1870

1890

2000

2390

2500

GY2510ES-HULR-

1000

2000 A

2500

10

890

1000

60

92

77

96

15

60

78

2750

7630

1890

2000

2390

2500

GY2525DS-HULR-

1000

2000A

2500

25

890

1000

47

96

84

74

12

47

60

930

2270

1890

2000

2390

2500
